Wheelchair Friendly

The large underfoot space of ST-26 allows a patient in a wheelchair to be examined quickly and comfortably. ST-26T with a T-shaped base has its column at the side of the table.

ST- 26H with a H-shaped base has its column at the center of the table.

• Wheelchairs with a front wheel outer width of 550mm or less are adaptable.
•  It is recommended to fold up the footsteps of the wheelchair during examination.

Careful Consideration of Cable Positioning

Access hole is strategically placed on the table top to allow a power cable through, and three auxiliary power outlets under the table top to power a full range of products without any need to run extra cables to a standard mains power supply.

The mains power cable for ST-26H extends from the side of the base eliminating interference with patient’s feet.

Heavy Load Capability (ST-26T:30 kg, ST-26H: 80 kg)

Large Elevation Stroke for All Patient Heights

A 300 mm elevation stroke to accommodate small to large patients sufficiently.

Space Saving Design with Various Kinds of Table Tops

*Please see the details in our brochure.
